Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter
Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter
Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter
Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter
Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter
Sub250 1s Nanofly16  1.6 inch Freestyle Quadcopter

Sub250 1s Nanofly16 1.6 inch Freestyle Quadcopter

SU000001

Regular price$149.99
/
Version
1s Nanofly16 1.6" Micro Quad with ELRS 2.4G / TBSNanoRX (TBS 915 Mhz)

HELLO everyone, Welcome to Sub250 Shop. We are very happy to introduce our first Ultra-light Freestyle FPV Drone Sub250 1s Nanofly 16 to you. it is very quiet, and suitable for both indoors and outdoors. Currently available in 2 versions: ELRS 2.4G, TBSNanoRX-TBS 915 Mhz

The design concept of Nanofly 16 quad is lightweight, small in size, has good hand feels, and is suitable for a variety of flight scenarios FPV traversing aircraft. Obviously, it exceeded the design specifications. We designed a 1.5mm carbon fiber body with a 3D-printed upper shell for the Nanofly 16. The fuselage has high strength and is very crash-resistant. We did a lot of tests and selected the Ant lens with better effect, which has a better imaging effect and less wide-angle distortion. We developed a 0803-19000KV strong magnetic motor with 40mm propellers, it has strong power and smooth throttle, which is very suitable for flying freestyle.

Nanofly16 has an ultra-light body weight with the latest 1S 380mAh high-voltage battery. The take-off weight of a drone is only 38.0g, and the flight time is 4.5 minutes. Equipped with a 3D printed battery holder, it is convenient and quick to replace the battery.

The most important thing is that Nanofly16 is very quiet to fly, like a dragonfly, you can both fly it at home and freestyle in the yard and even set up a few gantries for racing practice. Trust me, you'll love this small, portable, and quiet mini FPV drone after you fly it.



Features:
  • 1.6-inch tiny size & lightweight, just 28.0g
  • Includes a full set of high-quality 3D printed parts for a superior flying experience
  • It is equipped with a new F411-1S AIO/250mW/ELR Flight controller. Reliable & stable and easy to use.
  • Ant camera with a high-quality image. Clear and clean.
  • With a new 1S 380mAh battery with plenty of power output
  • The latest light 0803 - 19000KV motor is matched with 40 mm-2 propellers proving maximum power and efficiency
  • It is quiet, like a dragonfly, suitable for both indoors and outdoors.
  • Suitable for both freestyle and racing.
Specifications:
  • Brand Name: Sub250
  •  Model: Nanofly16
  • Frame: NF16
  • Wheelbase size: 77mm
  • Arm thickness: 1.5mm
  • Motor: M1 0803-19000KV
  • Weight:28.0g (ELRS)
  • Camera: Ant
  • MCU:STM32F411
  • IMU: ICM20689(SPI)
  • ESC: BLheli_S 4IN1 5A ESC
  • VTX: VTX 5.8G 250mW
  • Propeller: HQ 40mm-2
  • OSD:BetaFlight OSD w/AT7456E chip
  • Antenna: UFL 5.8G stick VTX antenna
  • Flight Controller: F411-1S AIO/250mW/ELRS
  • Receiver Version: ELRS 2.4G \ TBS 915 Mhz
  • Battery: Recommend 380mAh 1S 90C LiHV battery (Not include)
  • Flight Time:4 minutes and 45 seconds flight time with Sub250 latest 1S 380 mAh!

Package Includes:
  • 1 x Nanofly16
  • 4 x HQ 40mm-2 propellers
  • 1 x 3D printed battery holder
  • 1 x Phillips-head screwdriver
  • 1 x 1.5 mm screwdriver
  • 4  x  M1.4*3 Phillips screws

  • 3  x  M2*2 nylon nuts

Nanofly16 Manual

Diagram for Japan








    Affected by Covid-19, there will be some delays in the delivery.

    Shipping Methods and Charges
    We are currently able to ship orders to most international addresses. But some countries are not available to ship batteries without purchasing of whoop drone (logistics company restrictions).

    - Some remote address will be charged remote shipping fees according to the quotation of the logistics company.

    For the strict Customs Policy, countries below are not available for delivering batteries. Therefore, if you fail to purchase from our site, hope can you understand that. We'll open selling once there is a reliable logistics channel.
    -India (Both drones and batteries)
    -Kuwait

    Shipping Time:
    All orders will be processed within 3-5 working days after your payment clearing.
    If we are experiencing a high volume of orders or some products are out of stock, shipments may be delayed in a few days.
    If there will be a significant delay in the shipment of your order, we will contact you via email. Please make sure your email address is available and remember to check the email for the notification.
    Estimated Shipping Time:

    Expedited Shipping: 3-7 working days
    Standard Shipping (Registered Mail): 12-30 working days
    Please note:
    * These are estimated delivery times only, Sub250 can not guarantee an exact delivery time.
    * The estimated delivery time may be longer if any battery is included in your order.
    * Affected by Covid-19, there may be some delay in the delivery.
    * We accept no responsibilities and liabilities for the delay in shipping time as this is beyond our control.
    * Any problem about shipping info of your order, please contact Customer Support.
    Battery Shipping Issues
    - We can't ship the battery to the following countries by now: Indonesia / Middle / East / Indonesia/ Philippines/ Vietnam/ India/ Mexico/ UAE/ Brunei/ Finland/ Chile / Brazil / Oman and other remote areas. If your place an order but we don't have a logistic Chanel to ship, we will send an email to inform you to cancel the order.
    - For European customers, if your parcel includes only batteries, it will take a longer time for the parcel to arrive in your country. Click here to track your parcel.
    - If you only order batteries without a drone, then it can't be shipped by expedited Shipping (including DHL / FedEx / UPS) because of the strict restriction of shipping.
    - If the number of batteries in your order exceeds the acceptable range of the logistics, we will ask you to cancel the order or ship the batteries separately(an extra shipping fee may be required).
    More Info required
    If you are in Taiwan, South Korea, or Brazil, there is some extra information that we need in your order because of your country's import policy.

    Wrong Address
    Shipments will be sent to the address entered on our web page during checkout. We cannot be held responsible if the incorrect shipping address is entered by the customer during checkout. We can only modify a wrong address if customer contacts us before the package is marked as shipped.
    We cannot change shipping addresses after the order has been shipped, as the address information you enter is used as part of the fraud checks and fraud prevention. If additional fees are required to re-ship packages due to address errors, those fees may be passed on to the customer.

    Packages that are returned because of an incorrect address provided by the customer will be subject to an additional shipping charge. This shipping charge will apply even if you were not originally charged shipping under a free shipping promotion.

    Damaged box or incorrect item(s)
    If you receive damaged or incorrect item(s), contact Customer Support in 5 business days with receipt of your shipment to make the necessary corrections.

    * All duties and taxes are the responsibility of the customer.
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)
    Sub250 1S 380mAh 90C  Battery for Nanofly16 (2pcs/6pcs)

    Sub250 1S 380mAh 90C Battery for Nanofly16 (2pcs/6pcs)

    Regular price$26.99
    /
    Sub250 1S 380mAh 90C for  Nanofly16

    Sub250 1S 380mAh 3.8V LiHV High-voltage lithium battery is specially designed for Indoor Micro FPV drones. It is small volume, lightweight, and High capacity. It can discharge up to 90C, providing sufficient power for flight. Sub250 LiHV 1S battery’s USB charging board is used for charging, It’s extremely convenient and High-efficiency!
    The full charge voltage of the battery is 4.35V, the battery needs to be charged in time when the flight voltage drops to 3.6V!

    Specifications:
    Model: Sub250 1S 380mAh 90C Battery
    Model  Number: SUB3801S90AHV
    Capacity: 380mAh
    Configuration: 1S1P
    Nominal Voltage: 3.8V
    Type: LiHV
    Watt: 1.44WH
    Dimension: 48*17*6.5(mm)
    Weight: 9.7g
    Max cont. discharge (C-rate/current): 90C
    Charge Connector: GNB27
    Discharge Connector: GNB27
    Recommended charging current: 1C
    Maximum charging current: 3C
    Application: Toys, Boats, Quadcopter

    Feature:
    High Capacity
    lightweight
    Amazing discharge rate
    Long-lasting and durable

    Includes:

    2xSub250 1S 380mAh 90C

    Or 6 x Sub250 1S 380mAh 90C

    Warnings:
    Please read the battery parameters and instructions in detail before use.
    Please don’t charge the battery unattended.
    Do not overcharge (select the correct battery type before charging, the full charge voltage of a single cell of LiPo battery is not more than 4.2V, and the full charge voltage of a single cell of LiHV battery is not more than 4.35v).
    Do not over-discharge (the single-cell discharge voltage of LIPO and LiHV batteries cannot be lower than 3.5V, over-discharging will damage the battery and cause swelling).
    Don’t place the battery close to open flames or fire sources.
    Keep the battery away from flammable materials when charging
    Please carefully check the battery voltage and capacity before charging and use
    It is forbidden to reverse the positive and negative poles of the battery (to avoid short circuit)
    Do not directly touch the leaking battery. If you accidentally touch the electrolyte, please wash it with clean water immediately. If it is serious, please consult a doctor immediately.
    Please dispose of the ruptured battery in time and do not reuse it
    If you need to store the battery for a long time, please maintain the battery voltage at a single-cell 3.80V-3.85V. Please ensure that a charge-discharge activation is performed within 3 months to maintain the stability of the battery.
    It is forbidden to disassemble and reassemble the battery or change the wiring (it is easy to cause short circuits and burning).
    If a collision occurs during use, please remove the battery. Check carefully whether the battery and connector are normal.

    Pieces
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16
    Sub250 NF16 1.6 inch Frame for Nanofly16

    Sub250 NF16 1.6 inch Frame for Nanofly16

    Regular price$9.99
    /
    Sub250 NF16 1.6-inch Frame for 1.6-inch  Nanofly16 Micro Drone
    Brand Name: Sub250
    Model: NF16
    Wheelbase size: 77mm
    Bottom plate thickness: 1.5mm
    Camera plate thickness: 1.0mm
    FC mounting holes: 25.5mm x 25.5mm
    Motor mounting holes: 3-M1.4-EQS-Ø6.6
    Propeller size: 40mm
    Size:65mm x 65mm x 41mm
    Weight: 8.3g (including 3D print)
     Package Includes:
    1 x 1.5mm bottom plate
    1 x 3D printed top cover
    1 x 3D printed battery holder
    16 x M1.4 x 3 round head Phillips screws
    1 x M2 x 6mm round head screw
    3 x M2 x 12 round head screws
    1 x M2 x 14 round head screw
    4 x M2 x 6.6 shock absorbers
    8 x M2 x 2 nylon nuts
    1 x 1.5mm L-shaped screwdriver
    1 x Phillips screwdriver
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)
    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)

    Sub250 M1 0803 19000KV Brushless Motor for Nanofly16 (Pack of 4)

    Regular price$41.99
    /
    Sub250 M1 0803 19000KV Brushless Motor

    Sub250 developed the first M1 0803-19000KV brushless motor for the 1.6-inch toothpick quads. This motor is small in size and light in weight and is specially designed for micro drones.

    Feature:
    1. Small size and lightweight, only 2.2g.
    2. N52H strong magnetic magnet, high-temperature resistant coil, full of power.
    3. Low loss customization, low heat generation, and high efficiency.
    4. Suitable for a 1.4-1.6 inch micro drone.
    5.1.0mm shaft diameter is suitable for more propellers.

    Specifications:
    Brand Name: Sub250
    Model: M1 0803 19000KV
    Configure-ration:9N12P
    Voltage: 4.2V (1S)
    Stator Diameter:8.4mm
    Stator Length:2.8mm
    Shaft Diameter:Φ1.0mm
    Motor Dimension(Dia.*Len):Φ12mm*14mm
    Weight(g):2.2g
    No.of Cells(Lipo):1S only
    Battery: Recommend : 1S 380mAh-530mAh LiPo
    Suitable for 1.6-inch fpv drone
    The package includes a pack of 1 :
    1*M1 0803 19000KV Motor
    4x M1.4*3mm Screw

    The package includes a pack of 4 :
    4*M1 0803 19000KV Motor
    16x M1.4*3mm Screw
    Pack

    HQ 40mm-2 1mm Toothpick Propellers for Nanofly16

    SU000018

    Regular price$1.99
    /
    HQ 40mm-2 Propellers  for Sub250 Nanofly16
    Specification:
    Weight : 0.24g
    Propeller Diameter : 40mm
    Shaft: 1mm
    Pitch: 1 inch
    Blades: 2
    Material: Poly Carbonate
    Hub Diameter:5mm
    Hub Thickness: 5mm
    Color: Aquamarine

    Package Includes:
    2 x CW HQ  40mm  Micro Whoop Props
    2 x CCW  HQ  40mm  Micro Whoop Props
